J-SCIENCE | Compact Gas chromatograph
Features
- Exclusively for packed columns. Capillary columns cannot be installed
- Space-saving GC with limited functions and specialized for single analysis and space saving
-
OVEN is a constant temperature specification. (Temperature cannot be increased)
-
Equipped with one injection port
-
Only one detector is installed (TCD or FID)
-
Gas pressure control is analog control.
-
It is compact and has an extremely slim design with a device width of 300mm(A4 size)
|
Oven |
|
|
Temperature range : |
Room temperature＋５℃～３００℃ |
|
Temperature setting： |
１℃ step |
|
Temperature rising function： |
None |
|
Internal volume： |
180（w）×160（d）×265（h）mm |
Injector
Injector :
packed column inlet
Flow path method：
Single flow path method
Max temperature：
300℃
Temperature setting：
1℃ step
Flow control section
One-way type :
Analog control using
constant pressure valve
Setting range：
0 to 400 kPa
Detector
One
set of TCD or FID
Power, dimensions, weight
Power :
AC100 V 1500 W
Dimensions：
300（w）×525（d）×520（h）mm
Weight：
About 40㎏
